Measurement Range

-0.1~250MPa

Pressure type

Gauge, absolute ,sealed gauge

Output signal

4~20mA/ 0~5V/Switch/Digital

Display

5 digital LCD or 4 digital LED

Accuracy (%FS)

±0.1%（Typical） ±0.25%（Max.）

Nonlinearity (%FS)

≤0.1 (Typical)  ≤0.25 (Max.)

Hysteresis (%FS)

≤0.1 (Typical)  ≤0.25 (Max.)

Repetition (%FS)

≤0.1 (Typical)  ≤0.25 (Max.)

Stability

≤0.25

Temperature Error- Zero （%FS/℃）

≤0.02

Temperature Error –Span (%FS)

≤0.02

Ambient temperature

-20℃~60℃

Impedance

Adjustable

Power supply

12~36V (standard 24V)

Overload (%)

300

Life

9 Millions pressure cycles

Load impedance (Ω)

≤750

Response time (ms)

≤1

Measuring material

Compatible with 316L

Connector material

304, 316 stainless steel, Titan or Polytef

Diaphragm material

316L or ceramic

Pressure port

M20×1.5 G1/2, G1/4, 1/4 NPT or customize

Protection

IP65

Weight

280g
