Product Introduction

Vehicle speed sensors are designed for automotive engines, transmissions, and transfer cases. The sensors use magnetic

sensitive components and the principle of sensing changes in gear position to detect the position (teeth, grooves),

rotational speed, and position of gears made of magnetic materials. This product has high resolution, high frequency

response, non-contact measurement, output standard square wave and current signals, high protection level, and high

temperature resistance, and is widely used in the automotive field.

Technical parameter：

1.
   1. working temperature: -40°C~+125°C
   2. storage temperature: -40°C~+125°C
   3. work voltage: U Min: 4.5V， U Max: 20V
   4. frequency: 0~12KHz
   5. Low currency: 5.9~8.4mA，High currency: 11.8~16.8mA
   6. No obvious scratches on the appearance, smooth plastic surface, uniform color, no obvious depression
   7. smooth around edge
   8. Non-marked draft angle is 0.5 degrees, and non-marked rounded corners are R0.2
   9. material: PA66+GF30%


2. Marks

   AV: Active pulse single channel output                             HV: Square wave pulse

   IV: Active pulse dual output                                               LV: Passive sine wave

   FV: Analog voltage output                                                  CV: Speed measurement for automobiles
